Product Introduction
1)SD119 have UL268/521 and EN54-5/7 approvals
2)2 or 4 wire
3)5 year limited warranty
4) Advanced detection and discrimination algorithms
5) Easy installation and maintenance
6) Polished low-profile housing design
7) Durable sensor head, no need for replacement
8) SMD circuit board design: Satisfactory quality and reliability guaranteed
9) Integrated heat detector for SD119-2H and SD119-4H models
10) N/C (normal / close) and N/O (normal / open) relay output ways for option
11) AR (auto reset) function for security systems (optional for 4-wire models)
12) Sensor base: Standard and Schottky diode style for option
13) With two LED, more 360 degree visual angle
2)2 or 4 wire
3)5 year limited warranty
4) Advanced detection and discrimination algorithms
5) Easy installation and maintenance
6) Polished low-profile housing design
7) Durable sensor head, no need for replacement
8) SMD circuit board design: Satisfactory quality and reliability guaranteed
9) Integrated heat detector for SD119-2H and SD119-4H models
10) N/C (normal / close) and N/O (normal / open) relay output ways for option
11) AR (auto reset) function for security systems (optional for 4-wire models)
12) Sensor base: Standard and Schottky diode style for option
13) With two LED, more 360 degree visual angle
Main Parameter
Response Temperature: | 57°C (135°F) |
Ceiling Spacing: | 50 foot rating for heat sensor |
Reset Voltage: | less than 1 volt |
Alarm Indicator: | LED continuously emitting red light |
Remote Output: | 25 mA max., diode gate |
Temperature Range: | -10°C to 50°C |
Permissible Current: | 80mA maximum |
Humidity: | 0 to 95% RH, no condensation or icing |
Alarm Contact: | (for 4-wire) NO or NC Operation, Form A: 1.0A@30VDC/0.5A@125VAC |
Dimensions: | 100mm (dia) x 46mm (ht) with base |
Weight: | 120g/set with base |
