QL4518 Automatic Side Sealing Machine Introduction

1. QL4518 is the automatic side sealing machine which developed by ourselves, it is used to high capacity packing production line, feeding, conveying, entering bag, sealing can be finished at a time, it has high working efficiency.

2. Vertical sealing adopts high quality supporting structure and two sides linear guideway to make sealing pressure balanced, frame won’t be damaged easily. . The sealing knife adopts copper alloy sprayed with teflon, it won't stick film, sealing fastness, without smoke, non-pollution

3. Side sealing adopts constant temperature sealing knife, sealing part is straight and strong, there is no limited about packing object length. Film feeding belt adopts widen and thicken belt, its using life is long and easily to be replaced.

4. Machine adopt PLC controller, it is equiped with horizontal and vertical photo sensor to reach high speed and automatic working.

5. It is easy to change the size, just need adjust the handle, operation is easy.

6. It can be connected with a production line

7. it has protection function to avoid sealing product wrong and ensure the safety of operator

8. Optional function is front inlet feeding conveyor.

QL4518 Automatic Side Sealing Machine Main Parameter

Model	QL4518
Max packing size（mm）	L ∞,  W+2H≤450, H≤150
Max sealing size（mm）	W450
Power（KW）	1.4
Capacity	0-21 pcs/min
Voltage	220V 50/60HZ
Sealing temperature	160℃—240℃ depends on thickness of film and environment temperature
Thickness of film(mm)	0.015－0.10
Air pressure(Kg/cm2) )	5
Packing material	POF PVC
Machine weight(kg)	340
Machine size（mm）	L1700×W1000×H1500
